G6041G4RAS8U16

$6370.00

Parameter:

System form factor4U Rackmount

PCIe slot(8) FHFL dual-slot PCIe5.0 x16 / (1) FHHL PCIe5.0 x8

number of CPU sockets2

CPU series(Gen)AMD EPYC™ 9004 Series Processor

processor Socket TypeAMD Socket SP5

number of DIMM slots24

LIVE CHAT

Payment:

Shipping:

Description

Specifications
Form Factor	4U
Dimensions	438mm(17.2")W x 176.5mm(6.9")H x 786mm(30.9")D
Processor	(2) AMD EPYC? 9005/9004 series processors，TDP Up to 400W
Socket	(2) AMD Socket SP5
Chipset	System on Chip
Memory	(24) DDR5 DIMM slots (1DPC), RDIMM/RDIMM-3DS - Max. Frequency 4800MT/s - Max. Capacity per DIMM: RDIMM: 96GB RDIMM-3DS: 512GB
Storage	(24)hot swappable 2.5" drive slots, of which 16 support NVME *Additional RAID/HBA card required to support the 24 x 2.5" SATA/SAS drive bays (2) M.2 (PCle3.0 x4 or SATA 6Gb/s)
Networking	(2) GbE ports (Intel? i350)
Expansion Slot	Rear: (10)FHFL dual-slot PCle5.0 x16 slot (with PEX89104 PCle Switch) (1)FHFL single-slot PCle5.0 x16 slot (CPU direct link) (2)FHFL single-slot PCIe5.0 x8 slot, shared space with adjacent dual-slot (with PEX89104 PCIe Switch) Front: (2) FHHL PCle5.0 x16 slot (1)OCP NIC 3.0 slot ( PCle5.0 x16)
Front I/O	(1) Power button w/ LED (1) Reset button (1) NMI button (1) UID button (1) System fault LED (1) HDD activity LED (2) RJ45 (1GbE) by Intel i350, shares with Rear IO (1) dedicated IPMI, shares with Rear IO (4) Type-A (USB3.2 Gen1) (1) DB15 (VGA)
Rear I/O	(1) UID button (1) DB15 (VGA) (2) Type-A (USB3.2 Gen1) (2) RJ45 (1GbE) by Intel i350, shares with Front Panel (1) dedicated IPMI, shares with Front Panel
RAID	N/A
Server Management	ASPEED AST2600 (1) Realtek RTL8211F for dedicated management GLAN
Cooling	(5) Middle Hot-swap 80x80 mm fans
Power Supply	(3+1) redundancy 2000W CRPS 80+ Platinum
Environment	Operation temperature: 10°C ~ 35°C / Non operation temperature: -40°C ~ 70°C Non operation humidity: 20% ~ 90% ( Non condensing)
Package Contents	(1) 4U Barebone G6041G4RAS8U16 (1) Quick Installation Guide
